Bulk pack - 60W Rigid Solar Panel

The 60W PV Logic solar panel if often seen on roads powering illuminated street signage and belisha beacons and is often a standard fit for caravan and campervan manufacturers alike. Delivering up to 360W per day, the 60W panel is suitable for powering most DC and some AC appliances via a separately purchased inverter. Benefitting from a 10-year panel warranty, the 60W panel comes in a bulk pack of five. NOTE – A charge controller will be needed to protect a battery from reverse feed and overcharging. ... View more

£750.00
Product code: n/a
Product information

Overview

Powering a variety of energy needs

With power ratings from 5W to 80W, our rigid solar panels fulfil a variety of  energy needs, ranging from a continuous trickle feed of power to prevent battery drain in caravans, motorhomes and boats to creating energy self-sufficiency for off-grid travel.

Our rigid panels also deliver energy to remote power systems, such as electric fences and gates as well as pumps in garden ponds.

For more power, see our PV Logic MHD Rigid Solar Panel range in 100W to 200W.

Rigid solar panels rated 80W and above include bypass diodes to minimise the effect of shadows so that energy generation is maximised.

Rigid solar panels of 20W and above should be used with a charge controller to protect the battery from being overcharged and to prevent reverse current drain. Browse our range of charge controllers and for installation choose from our range of stands, brackets and fixings.

Product support

Find the user manual, advice on expanding a solar system and answers to frequently asked questions on our dedicated support page for PV Logic Rigid Solar Panels.

Features

Water resistant, robust construction for outdoor use.
Water resistant, robust construction for outdoor use.
In built diode protects against battery discharge
In built diode protects against battery discharge
Tough and robust
Tough and robust
10-year panel warranty
10-year panel warranty

Technical Specification



Power Size Weight
(kg)
Watts per
day (W)
Amp hours
per day (A)
Charge
Controller
Vmp (VDC) Imp (A) Voc(V) Isc(A)
5W 250 x 200 x 25mm 0.7 30 1.74 N/A 17.5 0.29 22 0.32 Download Tech Spec
10W 397 x 280 x 25mm 1.3 60 3.48 N/A 17.5 0.58 22 0.64 Download Tech Spec
20W 540 x 278 x 25mm 1.7 120 6.9 10A 17.5 1.15 22 1.27 Download Tech Spec
30W 660 x 380 x 25mm 2.7 180 10.3 10A 17.5 1.72 22 1.9 Download Tech Spec
45W 634 x 535 x 25mm 3.6 270 15.4 10A 17.5 2.58 22 2.86 Download Tech Spec
60W 670 x 640 x 35mm 4.5 360 20.94 10A 17.5 3.49 22 3.97 Download Tech Spec
60W (R) 1060 x 350 x 35mm 4.6 360 20.94 10A 17.5 3.49 22 3.97 Download Tech Spec
80W 836 x 670 x 35mm 6.7 480 27.9 10A 17.5 4.65 22 5 Download Tech Spec


Key

  • Vmp - Nominal voltage
  • Imp - Nominal current
  • Isc - Short circuit current
  • Watts and Amp hours/day based on six hours of average daily peak sunlight hours.



Contents
5 x 60W solar panel
10-year panel warranty

Warranty

The 60W PV Logic rigid panel comes with a 10-year warranty
